Weight indicator for areas classified as hazardous with protection methods according to:
ATEX II 2(2)G Ex ib [ib Gb] IIC T4 Gb for gases
ATEX II 2(2)D Ex tb [ib Db] IIIC T197°C IP65 Db for dust
Ideal for creating weighing systems, batching, and automation systems. EC-Type-Examination certificate according to Annex III (94/9/EC directive). CE-M approvable- OIML R-76 / EN 45501

MAIN FEATURES

• Waterproof 17-key numerical and functional keyboar
• LCD display with 6 25-mm high contrast digits, clearly visible even in poor lighting conditions and with low temperatures, and with 6 LEDs for showing the active functions
• Satined IP68 stainless steel case
• Dimensions 264x174x115mm
• Suitable for use on the table, or wall
• Up to 10.000e or multirange 3 x 3000e @ 0,3 µV/d in CE-M approved version for legal for trade use
• Up to 1.000.000 displayable divisions with internal resolution up to 3.000.000 points
• Up to 8 signal linearization points with DINITOOLS (3 from keypad)
• A/D 24-bit sigma-delta conversion, up to 200 conv./sec. autoselect
• Digital calibration and set-up from keyboard; Instrument management & configuration from PC with DINITOOLS
• Power supply through external module: with optional battery pack; or with optional power adapter connectable to mains at 230 Vac or at 24 Vdc
• Connection with up to 4 load cells having 350 Ohm input resistance
